Description
ENGINE
Engine Type: 197cc, Air Cooled, 4-stroke, single cylinder, Manual transmission
Start Type: Electric Start
Transmission: Chain Drive
Engine Gear: 4-3-2-1-N-R
Shift Gear: Foot
Max Torque: 8.5N.m/5000-5500r/min
Wheelbase: 43.9 inches
Ignition: CDI
Fuel Tank Capacity: 1.1 Gallons
CHASSIS
Front Hand Brake: Drum
Rear Foot Brake: Hydraulic Disc
Tire Front: 23x7-10
Tire Rear: 22x10-10
Front Suspension: 15.7 inches
Rear Suspension: 13.4 inches
Remote Control: No
Speed Limiter: Yes
Engine kill switch: Yes
DIMENSION
Battery: 12V/9Ah
G.W: 363.76 LBS
N.W: 308.65 LBS
Max Loading: 198 LBS
Overall Size: 69.3 x 42.1 x 43.3 inches
Carton Size: 55.9 x 33.0 x 34.3 inches
Seat Height: 31.89 inches
Ground Clearance: 5.32 inches
Tao Motor Cares: Read Owner’s Manual and all on-product warnings. ATVs can be hazardous to operate. For your safety, Always wear a helmet, eye protection, and protective gear. Never carry a passenger. Never ride under the influence of drugs or alcohol. Never ride on public roads or pavement. Be extra careful on difficult terrain. All children under the age of 16 riding ATVs should always have adult supervision at all times. Tao Motor also recommends that all ATV riders take a training course. For more information contact your local dealer or call (888) 908-3816 Tao Motor Inc. 2020
